Mezzanine guardrail bay
A straight run of railing with posts, a top rail, and a mid-rail for an interior edge.
An illustration of how the piece can be described. Not a record of a completed job, and no dimensions are given.
Spec
- Material
- Steel tube and flat bar
- Finish
- Joints ground flush, uncoated
- Application
- Interior edge guard
Parts of the piece
- Posts
- Hold the run upright at the edge.
- Top rail
- The continuous rail along the top of the bay.
- Mid-rail
- A second line between the top rail and the floor.
Briefing a job like this
What to include
Useful details: material, approximate size, where it will live, and any constraints you already know. For a job like this one:
- Run length and the height you need
- Where the posts fix to (floor, edge, slab)
- Whether joints should be ground flush
- Any rules or constraints you already know
